Lenovo G50-70 User Manual

34
G50-30/G50-45/G50-70/G50-70m/Z50-70 Hardware Maintenance Manual
1020 Base cover
Foraccess,removethisFRU:
• “1010Batterypack”onpage33
Figure 2. Removal steps of base cover
Removethescrews
1
.Thenremovethebasecover
2
.




Step Screw (quantity) Color Torque
1
M2.5×6mm,at-head,nylok-coated(3)
BigDoortoD
Black 2.5~3.0kgf*cm

Lenovo G50-70 Specifications

General

Operating System	Windows 8.1
Weight	2.5 kg (5.51 lbs)
Processor	Intel Core i3/i5/i7 (4th Gen)
RAM	Up to 8GB DDR3
Storage	Up to 1TB HDD
Display	15.6-inch HD (1366x768) or FHD (1920x1080)
Graphics	AMD Radeon R5 M230
Battery	Up to 4 hours
Optical Drive	DVD-RW
Connectivity	Wi-Fi 802.11 b/g/n, Bluetooth 4.0
Ports	1 x USB 3.0, 2 x USB 2.0, HDMI, VGA
