Lenovo IdeaPad 5i User Manual

Figure 16. Remove the fan
Screw specifications Number of screws
M2 x L3 2
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Fan
Remove the speakers
Make sure the following FRU (CRU) has been removed.
“Remove the lower case” on page 34
“Remove the battery pack” on page 35
Step 1. Disconnect the speaker cable from the system board and then remove the speakers.
Figure 17. Remove the speakers
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Speakers
Remove the I/O board
Make sure the following FRUs (or CRUs) have been removed.
40
Hardware Maintenance Manual

Lenovo IdeaPad 5i Specifications

General

RAM	16GB DDR4
Storage	1TB SSD
Graphics	Intel Iris Xe Graphics
Operating System	Windows 11
Audio	Dolby Audio, 2x 2W speakers
Camera	FHD 1080p with privacy shutter
Ports	HDMI, SD card reader
