Lenovo TAB 2 A7-10F Hardware Maintenance Manual

Lenovo TAB 2 A7-10F
31
1040 Battery pack
For access, remove this FRU:
• “1030 Back cover” on page 30
Figure 4. Removal steps of battery pack
Peel off the mylar as shown in the picture.
Insert the guitar pick to disconnect the connector as shown in the picture.
DANGER
Only use the battery specified in the parts list for your computer. Any other
battery could ignite or explode.

Lenovo TAB 2 A7-10F Specifications

General

Display Size	7.0 inches
Resolution	1024 x 600 pixels
Operating System	Android 4.4 (KitKat)
RAM	1 GB
Internal Storage	8 GB
Expandable Storage	microSD, up to 32 GB
Battery Capacity	3450 mAh
Primary Camera	2 MP
Front Camera	0.3 MP
Weight	269 g (9.49 oz)
Connectivity	Wi-Fi 802.11 b/g/n, Bluetooth 4.0
Processor	Quad-core 1.3 GHz Cortex-A7
Dimensions	189 x 105 x 9.3 mm
