IftheWindowsCerticateofAuthentication(COA)label8isattachedtoapartthatisreplaced,returnthe
oldpartwiththelabelattachedtothecustomer,orprovidealettertothecustomerstatingwhatthelabel
wasoriginallyonthecomputerandwhatthelabelpartnumber,serialnumber,andproductkeywere.
Whenyoureplacethebasecover,applythefollowinglabels:
3FCClabel4Serialnumberlabel
Thefollowinglabelsneedtobepeeledofffromtheoldbasecover,andneedtobeadheredtothenew
basecover.
1Ratinglabel
13China3GwirelessWANlabel
2RatinglabelforTaiwanonly
14SIRIMlabelorIndonesiaPOSTELlabel
5WWANMAClabel
15BrazilANATELlabelforwirelessWANcard
6Ratinglabel
16BrazilANATELlabelforBluetooth
7JapanGEOlabel
17BrazilANATELlabelforwirelessLANcard
9Assettag
18ChinaGEOlabel
10IsraelhomologationlabelforwirelessWANcard
19Non-encryptionlabel
11IsraelhomologationlabelforBluetooth
20Indonesiaratinglabel
12IsraelhomologationlabelforwirelessLANcard
21SwissSIMICCIDlabel
IfthebasecoverhastwoFCClabels,applybothtothenewbasecover.
2010LCDbezelassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1070PCIExpressMiniCardforwirelessLAN”onpage68
•“1080PCIExpressMiniCardforwirelessWANormSATAsolidstatedrive”onpage69
Chapter9.RemovingorreplacingaFRU99
