10.Reinstallarelabatteriaecapovolgerenuovamenteilcomputer,quindiricollegarel'adattatoredi
alimentazioneCAeicavi.
Sostituzionedelpoggiapolsi
Primadiiniziare,stamparequesteistruzioni.
PerrimuoverelePCIExpressCard,potrebbeesserenecessariorimuovereprimailpoggiapolsi.Leggerei
seguentiprerequisitieseguireleistruzioni.
Prerequisitiperlaprocedura
PERICOLO
Duranteitemporali,noncollegareoscollegareilcavodallapresatelefonica.
PERICOLO
Lacorrenteelettricachecircolaneicavidialimentazione,deltelefonoedicomunicazione
èpericolosa.Perevitarescosseelettriche,scollegareicaviprimadiaprireilcoperchio
dell'alloggiamento.
Rimozionedelpoggiapolsi
Perrimuovereilpoggiapolsi,procederenelseguentemodo:
1.Spegnereilcomputer,quindiscollegarel'adattatoredialimentazioneCAetuttiicavidalcomputer.
Attenderequalcheminutonoaquandolaparteinternadelcomputersiraffreddiprimadiprocedere.
2.AccertarsidirimuoverequalsiasischedainseritanelMediaCardReader.Chiudereilvideoecapovolgere
ilcomputer.
3.Rimuoverelabatteria.Vedere“Sostituzionedellabatteria”apagina91.
4.Rimuoverel'unitàottica.Vedere“Sostituzionedell'unitàottica”apagina105.
5.Rimuoverelevitichessanoilpoggiapolsidallaparteinferioredelcomputer.
Capitolo6.Sostituzionedelleperiferiche109
