Lenovo ThinkPad X1 Yoga Gen 8 User Manual

Type three: models with wireless WAN bracket only
Installation procedure
You computer supports two types of wireless WAN card.
• Type one: 4G wireless WAN card
Note: Attach the bracket to the wireless WAN card
1 . Insert the wireless WAN card and bracket into the
slot at an angle of about 20 degrees
2 , and pivot downward 3 . Install the screw to secure the wireless
WAN card and bracket.
4 . Ensure that you connect the blue cable to a connector and the orange cable to
b connector as shown 5 .
• Type two: 5G wireless WAN card
Notes: When installing, ensure the following items:
1. There might be a wireless WAN card bracket preinstalled on your computer. You might need to
remove the bracket before the installation of a 5G wireless WAN card.
Chapter 6. CRU replacement 51

Lenovo ThinkPad X1 Yoga Gen 8 Specifications

General

Memory	Up to 32GB LPDDR5
Weight	Starting at 1.38 kg (3.04 lbs)
Operating System	Windows 11 Pro
Audio	Dolby Atmos Speaker System
Processor	13th Gen Intel Core i7
Display	14" 2.8K (2880 x 1800) OLED, 400 nits
Display Option	Touchscreen
Graphics	Intel Iris Xe Graphics
Storage	Up to 2TB PCIe SSD
Battery	57Wh
Ports	2x Thunderbolt 4, 2x USB-A 3.2 Gen 1, HDMI 2.1, headphone/mic combo jack
Connectivity	Wi-Fi 6E, Bluetooth 5.2
Camera	FHD 1080p with ThinkShutter
Security	Fingerprint reader, dTPM 2.0
