Lenox LX - Magnetic Jet and Auto Fill System; How to Use the Magnetic Jet; Optional Auto Fill System

-20-
WARNING: DO NOT RUN DRY, BASIN MUST FILLED WITH WATER TO LEVEL INDICATOR.
CAUTION: MAGNETIC JET COVER ASSEMBLY MUST ALIGN WITH DISCHARGE PORT
POSITIONED AT 3/9 O’CLOCK.
When Ready to use, MAKEsurejetcoverispositionedat3/9O’clockforproperwhirlpool
actioninthebasin.Ifjetcoverisnotalignat3/9O’clock,waterwillsplashoutsideofthe
basin.
Proper way to use Magnetic Jet System:
1. Fill the water to water level indicator.
2. HoldMagneticJetrmlytobringclosertotheroundmagneticledanddonotreleasetheMagneticJetprematurelyor
thiswillcauseimpactsonthejetcoverandtheroundmagneticeld(housing)shorteningthelifeexpectancyofthejetcover.
Whenthejetcovernearstheroundmagneticeld,placejetcoverontothefourdimplearea(seediagram).Thejetcover
mustalignwithdischargeportspositionedat3/9O’clock.
3. Whennishedwithclient,DONOTremoveMagneticJetuntilmotorisfullystopped.
4. When motor is fully stopped, remove Magnetic Jet cover from the motor and remove jet cover and impeller for sanitation.
Motor
Round Magnetic Field (housing)
Magnetic
Jet Base
Magnetic
Impeller
Magnetic
Whirlpool Jet Cover
Bottom View of
Magnetic Jet Base
How to USE Magnetic Jet!
a. Automaticspallswithintelligentandreliablelevelsensor.
b. Time delay setting
c. Dualswitchedoutlets/Controlbox
d. Dual continuous outlets
e. Single drain pump controlled outlet with 3 minute timer (If drain pump requested as an option)
f. Heavy duty water valve
g. Operated in automatic or manual mode
i. Built in LED light power supply
j. Audibleoverowwarninginmanualllmode
J&A US A
iFill-Auto
Auto Fill System (Optional)
Feature & Operation
Dura Jet III Built - in
Electrodes Water Sensor
PressiFIll-Autotostartllthebasinand
once reaches water level
Whirlpool/lightwillbeactivated.
ManualOn/OffWater
ManualOn/OffSwitch
for Jet & Light
Time Delay Setting
Power On Indicator
Continuous Outlet (2 Amp)
ALL WIRES ARE INDICATED AS IT SHOWN
Drain Air Switch
Key Pad
Level Sensor
water Valve
12 AC Light
Auto Fill
Delay
Setting
Key Pad
Level
Sensor
Water
Valve
12 VAC
Light
Cont (2A)
iFill Delay
Setting
Power Cord
Power
LED
Drain (2A)Jet (2A)Light (2A)
Power Cord
Cont (2A)
INSTRUCTION
Water faucet MUSt be ON and desirable
temperature must be set with faucet handle before
using AUTO-FIll System.
1-PresstheiFill-Autobuttonwillllthebasinwith
water automatically.
Water valve will shutoff when water level is above the
sensor.
2-ProcesstheJETbuttonwillturnOn/OfftheJETand
LED light manually.
3-ProcessingthevalvebuttonwillturnOn/Offthe
water manually.
OPTIONAL AUTO FILL
OPTIONAL MOTOR
