WALL MOUNTING
The set can be mounted on a wall phone plate. If you do not have a modular wall
phone plate installed, we recommend that you consult with your telephone
company or installer to get one, or turn to page 11 for instruction.
1. Reversible HANDSET HOLDER - When the telephone is mounted on the wall,
the REVERSIBLE HANDSET HOLDER must be adjusted so it will hold the
handset.
1.SLIDE OUT
2.REVERSE
3.REPLACE INTO PHONE
2.To use as a wall phone you must use the plastic (box shape) WALL MOUNT
ADAPTOR.
10
ABOUT 7 INCHES
(plug into phone jack)
ABOUT 3 INCHES
(plug into wall jack)
WALL MOUNT ADAPTOR
SNAP THIS INTO THE BOTTOM OF THE
PHONE AS SHOWN ON THE NEXT PAGE
PH-319021201 MS V.1
E
