21
E
1 Important safety instructions
The ABC modules BM1, BM2 and BM3 may only be used with Digital plus by Lenz
®
or other
standard digital control systems with a NMRA-conformance seal. If in doubt, ask the system
supplier.
The current-carrying capacities stated below may not be exceeded as this could damage the block
section module.
2 Technical Data:
Maximum continuous current-
carrying capacity
3.0 A
Voltage at signal input (AC or DC)
DC: 11...24 V
AC: 8...24 V
Dimensions
70 x 60 x 20 mm
3 Requirements for using the ABC technology
To use the ABC technology with BM1, BM2 and BM3 block section modules, you will need
locomotive decoders of the GOLD- oder SILVER- series or other decoders that support the ABC
technology.
