Technical data
Electrical data
EL 1xx ECO (PLC)
4
20
LDCDS−EL100 EN 8.0
Screen
Typ EL xxx ECO
103
Type Touch screen, resistive
Colours 64 K
Display diagonal [cm] 8.9 (3.5")
Visible size [mm] 70 x 53
Resolution [pixels] 320 x 240
Pixel size [mm] 0.7 x 0.22
Contrast 400:1
Brightness [cd/m
2
] 300
Angle of view
right
left
top
bottom
[°] 65
65
50
60
Illumination LED
Service life at
25°C
[h] −
PLC functions
(EN 61131−3)
Typ EL xxx ECO PLC
103
Editor AWL, FUP, KOP, ST, AS, CFC
Program code [kB] 256
Data memory
Variables
Global Var.
[kB]
[kB]
64
64
Memory location [kB] 4
Process image
Input
Output
[kB]
[kB]
1
1
Retain data [kB] 16
UPS Integrated to save retain data to the flash memory
Target
L−force Logic
EL1xx
V2.x
Task runtime [ms] ³100
Ports
LAN
Type
Ethernet
Protocol TCP/IP
Baud rate 10/100 Mbits
Connection RJ45, socket
USB
Type 2.0 (1.1−compatible)
Connection Type A, socket
CAN
Type CAN, ISO11898
Protocol Lenze system bus CAN
Topology Line, terminated on both sides with 120 W
Node Master or slave
Number of nodes Max. 63
Baud rate See CAN communication manual
Bus length See CAN communication manual
Connection SUB−D, 9−pole, connector
