Maintenance
Maintenance operations
Checking the oil level
7
63
Lenze ¯ MA 12.0018 ¯ 4.1
Geared motor g500−S130/G50BS113 ... g500−S660/G50BS166
Check the oil level by means of the displayed dipsticks. Manufacture them according to
the mounting position.
Form template: dipsticks for g500−S130/G50BS113
M1, M4, M5
M3
M2
100
50
10
0
[mm]
M6
