Lenze g500-S660 User Manual

Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
117 158 3.7 352 158 7.147 25.056 S660 120S40 2 23
118 157 2.8 356 157 6.870 25.308 S400 120S40 2 17
119 155 4.6 359 155 8.330 25.511 S950 120S40 2 42
123 150 1.5 220 150 6.709 26.422 S220 120S40 2 14
133 139 3.7 402 139 7.109 28.548 S660 120S40 2 23
133 139 4.6 402 139 8.263 28.548 S950 120S40 2 42
136 136 2.4 400 136 6.744 29.156 S400 120S40 2 17
139 132 1.3 220 132 6.699 29.937 S220 120S40 2 14
145 127 3.4 438 127 6.967 31.167 S660 120S40 2 23
146 127 4.4 440 127 7.759 31.267 S950 120S40 2 42
153 121 1.3 220 121 6.651 32.867 S220 120S40 2 14
153 120 2.4 400 120 6.728 32.940 S400 120S40 2 17
163 113 4.4 492 113 7.714 34.989 S950 120S40 2 42
165 112 3.4 500 112 6.942 35.511 S660 120S40 2 23
169 109 2.2 400 109 6.674 36.267 S400 120S40 2 17
173 106 1.2 220 106 6.645 37.238 S220 120S40 2 14
188 98.2 2.7 545 98.2 6.790 40.333 S660 120S40 2 23
191 96.6 1.9 400 96.6 6.664 40.974 S400 120S40 2 17
191 96.4 3.4 578 96.4 7.287 41.067 S950 120S40 2 42
207 89.1 4.3 625 89.1 9.119 44.431 S2100 120S40 2 74
214 86.2 2.6 620 86.2 6.775 45.956 S660 120S40 2 23
214 86.2 3.4 647 86.2 7.261 45.956 S950 120S40 2 42
228 80.9 1.8 446 80.9 6.711 48.950 S660 120S40 2 23
229 79.4 2.3 625 79.4 6.890 49.867 S660 120S40 3 23
229 79.2 3.4 693 79.2 7.578 50.027 S950 120S40 3 43
230 80.2 4.3 695 80.2 9.036 49.378 S2100 120S40 2 74
232 79.5 2.8 701 79.5 7.078 49.840 S950 120S40 2 42
244 75.7 4.3 736 75.7 9.651 52.311 S3100 120S40 2 114
251 73.4 3.6 759 73.4 8.411 53.924 S2100 120S40 2 74
257 70.7 3.0 776 70.7 7.561 55.982 S950 120S40 3 43
260 71.0 1.8 508 71.0 6.701 55.773 S660 120S40 2 23
260 71.0 2.8 785 71.0 7.060 55.773 S950 120S40 2 42
261 69.7 2.1 650 69.7 6.881 56.818 S660 120S40 3 23
275 66.9 4.3 832 66.9 9.459 59.156 S3100 120S40 2 114
279 66.1 3.6 843 66.1 8.354 59.927 S2100 120S40 2 74
293 62.9 2.1 668 62.9 6.872 63.000 S950 120S40 2 42
293 62.1 1.9 660 62.1 6.770 63.817 S660 120S40 3 23
294 61.9 2.7 887 61.9 7.244 64.022 S950 120S40 3 43
296 62.4 3.6 893 62.4 8.772 63.487 S3100 120S40 2 114
317 58.1 2.9 959 58.1 7.759 68.162 S2100 120S40 2 74
320 56.7 1.7 660 56.7 6.735 69.813 S660 120S40 3 23
321 56.5 2.7 950 56.5 7.143 70.037 S950 120S40 3 43
322 56.3 5.8 974 56.3 8.679 70.302 S2100 120S40 3 75
328 56.2 2.0 736 56.2 6.861 70.500 S950 120S40 2 42
329 55.3 2.6 950 55.3 7.234 71.644 S950 120S40 3 43
334 55.2 3.6 1010 55.2 8.641 71.793 S3100 120S40 2 114
334 54.5 1.8 660 54.5 6.764 72.713 S660 120S40 3 23
353 52.3 2.9 1066 52.3 7.724 75.750 S2100 120S40 2 74
353 51.5 5.3 1066 51.5 8.432 76.907 S2100 120S40 3 75
358 50.7 5.2 1083 50.7 8.646 78.128 S2100 120S40 3 75
360 50.5 2.4 950 50.5 7.134 78.375 S950 120S40 3 43
365 49.8 1.7 660 49.8 6.730 79.545 S660 120S40 3 23
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
