Mechanical installation
Mounting of g500 short/servo adapters with clamping connection
Attachment of gearboxes with hollow shafts and keyway
4
39
Lenze ¯ MA 12.0018 ¯ 4.1
K12.0611
Auxiliary tool (recommended dimensions)
Æ d
H7
d
2
c
7
18
20
M6 4
25
30
M10
5
6
35 M12 7
40
45
50
M16
8
9
10
55
60
65
70
80
M20
11
13
13
14
16
90
100
120
M24
20
24
24
Tab. 3 Dimensions in [mm
6. Cover rotating screw heads, interfering edges, slots or similar items safe against
contact.
