Lenze IoT Gateways x510 LAN - Mechanical Installation; Important Notes on Mechanical Installation

Mechanical installaon
Important notes
NOTE
The specied installaon clearances are minimum dimensions to ensure a sucient air circulaon for cooling
purposes. They do not consider the bend radiuses of the connecng cables.
Mounng and dismounng
②
B
A
①
Dimensions
95
28
25 25
25
111
116
RDY
L
x520
Mechanical installaon
