Lenze L-force Series User Manual

X100 (400 V) 230  45 kW

9
EDK84VHCE453 DE/EN/FR/ES/IT 1.3
2
X100 (400 V)
30  45 kW
X100 − TN, TT
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1…F3
K
Z
PE
L3
L1
+UG -UG
L2
X100
8400GG090a 8400GG007
X100 − IT
3/N/PE AC 400 V / 500 V
L1
L2
L3
N
PE
F1…F3
K
PE
L3
L1
+UG
-UG
L2
X100
8400GG090b 8400GG008
F L1, L2, L3 PE
EN 60204 UL
[A] [A] [A] [A] [mm
2
]
[AWG]
[mm] [Nm]
[lb−in]
[mm
2
]
[AWG]
[mm] [Nm]
[lb−in]
E84AVHCE3034 80 C80 − − − −
16 ... 50
6 ... 0
24
4.0
35
2.5 ... 25
12 ... 2
16
4.0
35
E84AVHCE3734 100 C100 − − − −
E84AVHCE4534 125 C125 − − − −
