Flange mounng
Depending on the ordered version, dierent anges can be mounted to the gearbox.
Please pay aenon to the order codes marked on the packaging!
You need:
•
Allen key for xing screws
•
Screw locking adhesive (recommended: Locte 243)
Perform the following acvies:
1.
Clean connecng surface of gearbox and ange.
2.
Apply a thin layer of securing adhesive to the thread of the xing screws.
3.
Mount ange to the gearbox. Push the centring at the ange into the center hole of the gearbox unl
both connecng surfaces have contact
4.
Tighten xing screws with the given torque.
Thread / property class Tightening torque [Nm]
M6 / 8.8 11
M8 / 8.8 25
Mechanical installaon
Mounng
Product extensions
58
