Assembling
© 2020 -All rights reserved! Copying is strictly prohibited!
3.3.5 Install the bridge and strings
Put the bridge on the bridge position and let it press
and contact the ground cable wire, then for measure
it. From the nut to the bridge saddles is 34"(864mm)
as a scale length. Then use a pencil mark the line of
bridge.
Check the steel ruler is go through on the middle of
the top of the finger board inlay, then adjust the
bridge position for more right or more left. There is 5
holes on the bridge, let the 3rd(middle) hole align the
ruler. Mark the 5 holes and pre-drill, then for fix them
with the bridge screws.
Let the 4 strings go through the hole from the bottom
of the bridge, and leave the ball-end here. The treble
string on the right side, and the bass string on left
side.
Rolling the strings to the column of the machine
heads, at most 2 and half circles otherwise there is no
space to keep the thicker bass string rolling on the
column.
LB -400Bass DIY Kit
