Leon's L2 MOTION LUX - Setup the Power Foundation Without the Bed Frame

1
Open the box lid.
HEAD BOARD
1
STOP
2
HEAD FOOT LUMBAR
2
Take out all the accessories from the packaging and put
them aside. All electronics and components that need to
be installed are located in boxes under the foundation or
attached to the frame. Before discarding the packing
materials, ensure that all the parts are accounted for.
×1(2 for K/CK)
Mattress Retainer Bar
×1
Accessories Box
ACCESSORIES BOX:
×1
AC
Power Cord
×1
Remote
Control
×1
Power Supply with
Battery Backup Box
9V
9V
9V
(Optional)
×3
AAA
Batteries
AAA
×1
Sync Cord
（TXL Only）
Setup the power foundation without the bed frame.
×6
Adjustable Legs
Remove the red plastic safety lock before unfolding your power foundation.
3
Remove the red plastic
safety clip.
Red Plastic
Safety Clip
Remove the folding locking
pin by pulling upwards.
Locking Pin
Turn the locking pin 90° in
counter clockwise direction.
Locking Pin
