4 • USER MANUAL LEONE ARROW E-SCOOTER
1 - Rear rack
2 - Rear light
3 - Rear directional light
4 - Rear side reector
5 - Rear reector
6 - Rear fender and registration plate holder
7 - Rear wheel
8 - Centre stand
9 - Passenger footrest
10- Front wheel
11 - Front fender
12 - Front directional light
13 - Front light
14 - Rearview mirror
15 - Ignition
16 - Battery box + connection point charger
17 - Saddle
1
2
4
3
5
6
7
8
9
10
11
12
13
14
15
16
17
