7
STORAGE RACK
INSTRUCTIONS
6. Attach x4 Hanger Tube (Centre) (4) to the Spine Tube
(1), and fasten with x2 Carriage Bolt (9), x14 Carriage
Bolt (10), x2 Curve Washer (12), x14 Washer (11) and
x16 Nylon Bolt (13).
7. Once all of the fixings are fully tightened the rack
can be placed in position and is ready for use.
Spine Tube
Hanger Tube (Centre)
To Next Page
