LevelOne IGP-0501 User Manual

7
Alarm Relay Contact
Relay outputs with current carrying capacity of 1 A
@24VDC,
Relay in short circuit mode when 2 powers are
connected. in open circuit mode when only one
power supply is connected
POE power
POE power per port 30watts. Maximum 36Watts
Maximum total power 126Watts, Supports
IEEE802.3af/at
Removable Terminal Block
Provide 2 Redundant power , Alarm relay contact ,6
Pin
Wire range: 0.34mm^2 to 2.5mm^2
Solid wire (AWG):12-24/14-22
Stranded wire(AWG): 12-24/14-22
Torque:5lb-In/0.5Nm/0.56Nm
Wire Strip length: 7-8mm
Operating Temperature
-40℃~75℃ fully tested.
Operating Humidity
5% to 95% (Non-condensing)
Storage Temperature
-40℃~85℃
MTBF (mean time between failure)
510,304 hrs ( MIL-HDBK-217F) at 25°C
Housing
Rugged Metal ,IP30 Protection
Case Dimension (L x W x D)
142mmx43mmx105mm (LxWxD)
Installation mounting
DIN Rail mounting and Wall Mounting
Certifications:
EN55022/24
ITE equipment
EN50155
Railways Applications Electronic Equipment used
on Rolling Stock
EN55011
Industrial, Scientific and Medical (ISM) equipment
EN50121-3-2
Railway Applications – Electromagnetic
Compatibility – Part 3-2 Rolling Stock - Apparatus
EN50121-4
Railway Applications – Electromagnetic
Compatibility – Part4 Emissions and Immunity of
the Signaling and Telecommunications Apparatus
Safety
IEC EN60950-1
EMC/EMS
CE, FCC, VCCI
EMI
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
EN 50155 / EN 60068-2-6
Vibration
EN 50155 / EN 60068-2-27
Shock
EN 50155 / EN 60068-2-32
Free Fall
