❖ Features
 With 8*10/100/1000M PoE downlink ports,2*1000M SFP ports;
 Provides two modes of Default and VLAN to adapt to various complex environments;
 Supports PoE Auto-check function, which is specially designed to solve the problems of equipment frozen. It can
automatically detect the frozen PD equipment and restart the ports’ output of PSE, and restart the PD device. It
greatly reduces the maintenance difficulty of engineering;
 Supports relay alarm for power off, network broken, PoE off ;
 6KV surge protection, 8KV contact /15KV air ESD protection;
 Supports working temperature -40℃～75℃.
❖ Specifications
Parameter Specifications
Power supply Powered by power adaptor
Range of voltage DC 48~57V
Consumption Self consumption<15W
Downlink ports Ports 1~8 10/100/1000Base-T PoE RJ45 ,Support IEEE 802.3af/at
Uplink ports Ports 9~10 1000M SFP slots
PoE Auto-check If detect the frozen PD device, restart it
Working mode
Default mode: normal switch mode.
VLAN mode: ports 1 ~ 8 are isolated from each other and can only communicate with the
uplink port; restrain the network storm; turn off the flow control.
Cable and distance
Use cat5e/6,100m max(Extend mode max, 250m)
Standard
IEEE802.3, IEEE802.3u, IEEE802.3z
Switch fabric
20Gbps
Though put
14.88Mpps
Buffer
1M
MAC address table
8K
Indicator
Power: 1 *red ;
Uplink 9~10: green LEDs indicate Link/Act
Downlink 1~8: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE
Protection
Surge: 6KV, standard: IEC61000-4-5
ESD: 8KV: contact/15KV: air, standard:IEC61000-4-2
Working temperature
-40℃~75℃
Storage temperature
-40℃~85℃
Humidity
0~95%(No condensation)
Dimension(L×W×H)
165 mm×114 mm×50mm
Material
Metal
Colour
Black
Net-weight
1000g
