- 7 -
2. Device Overview
Panel Overview
Top Panel
Adapter Socket
(12V/1A)
The power socket for connecting to an external power source
through the power adapter provided in the package.
DC Socket (DC12V)
The power socket for connecting to an external power source
through a DC power supply.
Restart Button
Press to restart DSA-1000.
Ethernet Port
Ethernet port for connecting to a Controller/Gateway.
