• For each active LAN (PC) connection, the LAN
LED on RJ-45 should be ON.
o
Configuration
1. Start your PC. If it is already started, restart it.
It will then obtain an IP Address from the Wireless
Router's DHCP Server.
2. Start your WEB browser. In the Address box, enter
the following:
HTTP://192.168.0.1
3. Click Setup Wizard to proceed initial setup
4. Step through the Wizard until finished. Refer to the
data from your ISP, and the table below, to ensure
your choices are correct.
Connection Type Data required.
Dynamic IP Ad-
dress
Usually, none.
But some ISP may require a
particular Hostname, Domain
name, or MAC (physical) ad-
dress.
Specified (Fixed)
IP Address
IP Address allocated to you,
and related information.
PPPoE Login name and password.
PPTP, Big Pond,
L2TP
Login name and password,
Server Address
5. On the final screen of the Wizard, run the test and
check that an Internet connection can be established.
• If the connection fails, check both your data and
the Cable/DSL modem.
