ODS06
Leviton Mfg. Co., Inc. Lighting & Energy Solutions
201 N. Service Rd. Melville, NY 11747-3138 Tech Line: 1-800-824-3005 Fax: 1-800-832-9538 www.leviton.com/les
© 2014 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
ODS06 Wall Switch Occupancy Sensor Wiring
Diagram, Single Location Control
ODS06 Wall Switch Occupancy Sensor Wiring
Diagram, Multi-Location Control
Hot (Black)
Load
ODS06
Black
Green
Ground
Blue
Line
120-130-277VAC,
50/60Hz
Neutral (White)
Black
White
Note: Ground must be connected
WIRING DIAGRAM
DIMENSIONAL DIAGRAMS
1.75”
(44.4 mm)
1.30”
(33.0 mm)
2.61”
(66.3 mm)
4.06”
(103.2 mm)
0.48”
(12.6 mm)
1.35”
(34.4 mm)
2.60”
(66.2 mm)
BLINDERS
RANGE
TIME LIGHT
1
2
3
4 7
10
4 7
10
Mounting Yoke
Vandal Resistant
PIR Lens
Patented
Blinders
LED Window and
Light Sensor
Push Button
Control Panel,
Cover Removed
Hot (Black)
Load
ODS06
Black
Green
Ground
Blue
Blue
Green
Ground
Line
120-230-277VAC,
50/60Hz
Neutral (White)
Black
White
Black
Note: Ground must be connected
To Next Page
