Leviton IPHS5-1LW - Wiring and Settings; Wiring Diagram; User Adjustable Settings

Dimensional Drawing
1.75
44.5
4.13
104.8
3.81
96.8
3.28
83.3
0.37
9.3
1.22
30.9
2.72
69
Cat. No. IPHS5
Wiring Diagram
User Adjustable Settings
Hot (Black)
Neutral (White)
Required For Operation
BKWH
Sensor
Black
White
RD
Green
Ground
Line
120 VAC, 60Hz
R
ES
ET
RE
S
ET
T
ES
T
T
EST
2
2
1 3
2
3
1
4
20
off
Lo
Md
of
f
Hi
cycle
80
Sensitivity
Lo Md
Off
Off
Hi
Time Humidistat
2 3
1 4
20 80
cycle
(10 min.) (45 min.)
(20 min.) (30 min.)
(Stop Mark)
1
2 3
1
SENSITIVITY Adjust low, medium or high the sensitivity to ambient humidity changes
2
TIME Adjust the minimum ON time of fan
3
HUMIDISTAT Turn ON the air cycle or adjust the humidity set points
