Levitronix BFS-i06 User Manual

User Manual for BFS-i06
www.levitronix.com
PL-3502-00, Rev04, DCO# 24-054
This document and its content is confidential and the property of Levitronix
®
and shall not be reproduced, distributed,
disclosed or used for manufacturing or sale of Levitronix
®
products without the expressed written consent of Levitronix
®
.
14
Pin
Wire Color
Designation
Description
Standard Levels
Power Connector:
TE D3200 1-178128-3
Counterpart:
TE D3200 1-178128-3
1
Red
Power +
Supply
+ 48 VDC ± 10 %
+ 24 VDC ± 5 % (reduced performance)
2
Black
Power -
Supply
Internally connected to cable shield
3
Yellow-green
GND / earth
Cable shield
To be connected to earth
PLC Connector:
TE D1200 1-1827864-6
Counterpart:
TE D1200 1-1903131-6
B4
Pink
Digital input 1
Default: not used
(Configurable: enable / reset)
B5
Gray
Digital input 2
Process / speed mode switch
5…24 V (min. 30 ms)  Process mode
0 V / n.c. (min. 30 ms)  Speed mode
B3
Yellow
Digital input ground
Reference for digital inputs
B6
Violet
Analog input 1
Setpoint speed / process value
and enable / reset fan
4…20 mA  0…13000 rpm / 0…100 % setpoint
> 3.5 mA (edge triggered)  On / reset
B1
Gray-pink
Analog input 2
Actual process value
(pressure or flow sensor)
4…20 mA  0…100 %
B2
Blue
Analog input ground
Reference for analog inputs
A2
Brown
Digital output 1
System status signal
Circuit closed  Power output on
Circuit open  Power output off
Ground (A4) is reference
A3
White
Digital output 2
Error signal
Circuit closed  No errors present
Circuit open  System is in error state
Ground (A4) is reference
A1
Blue-red
Analog output
Actual speed
0…13000 rpm  4…20 mA
Ground (A4) is reference
A5
Brown-green
RS485 +
RS485 interface
Modbus protocol
A6
White-yellow
RS485 -
A4
White-green
Ground
Reference for digital and analog
outputs
GND / earth (internally connected to power - and cable
shield)
Table 5: Standard configuration of motor connectors
Note: Levels and assignments of analog and digital inputs and outputs are configurable in Levitronix
®
Service Software or through
Modbus protocol. See firmware specification (SW-3502-04) for detailed information
Pin
YN-485I-TR
Open wire to USB adaptor
ICS-1.2
Open wire to user panel LUI-B
ICS-1.3
Interface panel FIP to USB adaptor
1
-
RS485+
RS485+
2
-
RS485-
RS485-
3
-
Ground
Ground
4
Ground
-
-
5
RS485-
-
-
6
RS485+
+ 24 VDC supply for LUI-B
-
Table 6: Pin definition of screw type connectors on adaptor cables

Levitronix BFS-i06 Specifications

General

Brand	Levitronix
Model	BFS-i06
Category	Fan
Language	English
