LEWA ecosmart LCA - 1 General Information; Safety; Important Preliminary Information; Application; Performance and Applicabilities

9 pages

To Next Page

To Previous Page

1 General information / safety

1.1 Important preliminary information

Refer to operating instruction B 0.100.1.

1.2 Application

This operating instruction applies to the

drive element LEWA - ecosmart

type LCA with manual stroke adjustment,

motor mounted vertically.

The LEWA works number can be found in the technical data sheet and on the nameplate xed to the

drive element casing.

1.3 Performance and applicabilities

See technical data sheet.

Plunger rod thrust: 1330 N

Stroke length: 0 - 15 mm

Scale division longitudinal scale: 1,00 mm

Ring scale: 0.05 mm

Attachable pump heads: diaphragm pump heads

Fig. 1

B 1.660 en Drive element LEWA - ecosmart® type LCA manual stroke adjust., motor vertically
