FROM
FEB ‘99
Page 25
CONCEPT/OCEAN 2 & 3 PARTS LIST • CONCEPT/OCEAN 2 & 3 TEILE-LISTE •
LISTE DES PIECES DETACHEES DES CONCEPT/OCEAN 2 & 3 • DESPIECE MODELOS DEL CONCEPT/OCEAN 2 & 3 •
RESERVDELSLISTA FÖR MODELLERNA CONCEPT/OCEAN 2 & 3
Concept 2 Concept 3 Concept 2 Concept 3 Ocean 2 Ocean 3 Ocean 2 Ocean 3 Capstan 2 Capstan 3
1 Motor/Gearbox 12v 1 68000213 68000215 68000213 68000215 68000235 68000237 68000235 68000237 68000213 68000215
1a Motor/Gearbox 24v 1 68000214 68000216 68000214 68000216 68000236 68000238 68000236 68000238 68000214 68000216
1 Motor/Gearbox 12v 1 68000530 68000534 68000530 68000534 68000532 68000536 68000532 68000536 68000530 68000534
1a Motor/Gearbox 24v 1 68000531 68000535 68000531 68000535 68000533 68000537 68000533 68000537 68000531 68000535
2 Spirol clip 1 B7782 B7782 B7782 B7782 B7782 B7782 B7782 B7782 B7782 B7782
3 Drive Key 1 65000443 65000443 65000443 65000443 65000772 65000772 65000772 65000772 65000443 65000443
4 Shaft 1 65000445 65000446 65000448 65000448 65000445 65000446 65000448 65000448 65000511 65000508
4a Shaft 8" Extention Kit 1 68000352 68000354 68000355 68000355 68000352 68000354 68000355 68000355 N/A N/A
5 Bearing 1 65000441 65000441 65000441 65000441 65000441 65000441 65000441 65000441 65000441 65000441
6 Circlip 1 B6126 B6126 B6126 B6126 B6126 B6126 B6126 B6126 B6126 B6126
7 Delrin Washer 1 65000259 65000259 65000259 65000259 65000259 65000259 65000259 65000259 65000259 65000259
8 Sealing Gasket (Grey) 1 65000442 65000442 65000442 65000442 65000442 65000442 65000442 65000442 N/A N/A
8a Sealing Gasket (White) 1 65000595 65000595 65000595 65000595 N/A N/A N/A N/A N/A N/A
9 Base (Grey) 1 65000764 65000764 65000764 65000764 N/A N/A N/A N/A N/A N/A
9a Base (White) 1 65000780 65000780 65000780 65000780 N/A N/A N/A N/A N/A N/A
9b Base (Chrome) 1 N/A N/A N/A N/A 65000771 65000771 65000771 65000771 65000526 65000526
10 Seal 1 B2580 B2580 B2580 B2580 B2580 B2580 B2580 B2580 B2580 B2580
11 Seal Washer 1 65000437 65000437 65000437 65000437 65000437 65000437 65000437 65000437 65000437 65000437
12 Rubbing Washer 1 65000438 65000438 65000438 65000438 65000438 65000438 65000438 65000438 65000438 65000438
13 Lower Cone 1 65000436 65000436 65000436 65000436 65000436 65000436 65000436 65000436 65000170 65000170
14 Gypsy 201 1 68000356 68000356 68000356 68000356 68000356 68000356 68000356 68000356 N/A N/A
14a Gypsy 202 1 68000357 68000357 68000357 68000357 68000357 68000357 68000357 68000357 N/A N/A
14b Gypsy 203 1 68000358 68000358 68000358 68000358 68000358 68000358 68000358 68000358 N/A N/A
14c Gypsy 204 1 68000359 68000359 68000359 68000359 68000359 68000359 68000359 68000359 N/A N/A
14d SKT HD CAP Screw M5x20 4 B0677 B0677 B0677 B0677 B0677 B0677 B0677 B0677 N/A N/A
14e Spirol Pin 3 B1525 B1525 B1525 B1525 B1525 B1525 B1525 B1525 N/A N/A
15 Chain Stripper Only 1 65000775 65000775 65000775 65000775 65000775 65000775 65000775 65000775 N/A N/A
15a Chain Stripper Screw 1 65000439 65000439 65000439 65000439 65000439 65000439 65000439 65000439 N/A N/A
16 In-fill Piece 1 65000776 65000776 65000776 65000776 65000776 65000776 65000776 65000776 N/A N/A
16a Screw 1 65000565 65000565 65000565 65000565 65000565 65000565 65000565 65000565 N/A N/A
17 Chain pipe cover (Grey) 1 65000778 65000778 65000778 65000778 N/A N/A N/A N/A N/A N/A
17a Chain pipe cover (White) 1 65000781 65000781 65000781 65000781 N/A N/A N/A N/A N/A N/A
17b Chain pipe cover (Chrome) 1 N/A N/A N/A N/A 65000779 65000779 65000779 65000779 N/A N/A
18 Skt Hd Cap Screw M6x25 2 65000439 65000439 65000439 65000439 65000439 65000439 65000439 65000439 N/A N/A
19 Skt Hd Cap Screw M6x60 1 65000440 65000440 65000440 65000440 65000440 65000440 65000440 65000440 N/A N/A
20 Upper Cone 1 N/A N/A 65000435 65000435 N/A N/A 65000435 65000435 N/A N/A
21 Top Nut Washer 1 N/A N/A 65000262 65000262 N/A N/A 65000262 65000262 N/A N/A
22 Top nut 1 N/A N/A 65000434 65000434 N/A N/A 65000434 65000434 N/A N/A
23 Drum Assembly 1 68000241 68000242 N/A N/A 68000241 68000242 N/A N/A 68000312 68000313
24 Drum Washer 1 65000263 65000263 N/A N/A 65000263 65000263 N/A N/A 65000263 65000263
25 Drum Top Nut 1 65000176 65000176 N/A N/A 65000176 65000176 N/A N/A 65000176 65000176
26 Pawl 1 N/A N/A N/A N/A 65000551 65000551 65000551 65000551 N/A N/A
27 Sleeve 1 N/A N/A N/A N/A 65000782 65000782 65000782 65000782 N/A N/A
28 Ball Spring Delrin 1 N/A N/A N/A N/A B1554 B1554 B1554 B1554 N/A N/A
29 Skt Hd Screw M6x16 1 N/A N/A N/A N/A B0679 B0679 B0679 B0679 N/A N/A
30 Spacer 1 N/A N/A N/A N/A 65000741 65000741 65000741 65000741 N/A N/A
31 Adaptor Plate 1 N/A N/A N/A N/A 65000773 65000773 65000773 65000773 N/A N/A
32 Screw 4 N/A N/A N/A N/A B0008 B0008 B0008 B0008 N/A N/A
33 Screw 8 N/A N/A N/A N/A 65000773 65000773 65000773 65000773 N/A N/A
Arm Kit (Complete) 1 68000499 68000499 68000499 68000499 68000499 68000499 68000499 68000499 N/A N/A
34 Arm 1 65000762 65000762 65000762 65000762 65000762 65000762 65000762 65000762 N/A N/A
35 Spring 1 65000542 65000542 65000542 65000542 65000542 65000542 65000542 65000542 N/A N/A
36 Screw 1 65000763 65000763 65000763 65000763 65000763 65000763 65000763 65000763 N/A N/A
CONCEPT 2 & 3 WINDLASS OCEAN 2 & 3 WINDLASS CAPSTAN 2 & 3
Item Description Qty Gypsy Capstan Gypsy Only Gypsy Capstan Gypsy Only
