Lexicon, Inc.
MC-12 Serial Communications Protocol Printed on: 10/10/02
© 2002 Lexicon, Inc. All rights reserved. 25 of 92
The MC-12 will assign the value from the packet to the front/back balance.
7.3.20.4 Data Validation
If a value is passed that exceeds the maximum value of that parameter the MC-12 will ignore the command
and transmit a NAK command with an error code DC_INVALID_DATA.
7.3.21 Set Active Effect by Id (MC-12, MC-1)
This command requests the MC-12 to set the active effect to the value in this packet.
This command has been maintained for backward compatibility with MC-1. In order to maintain backward
compatibility, the MC-12 Parameters have been mapped to the MC-1 parameters as described in each Data
Description. MC-12 users should be using the command described in 7.3.50
(MC12_Set_Active_Effect_By_Id).
7.3.21.1 Command Packet Description
Application Header:
Command DC_CMD_SET_EFFECT 0x24
Data Count 1 0x01
Application Data:
Data[0] EffectId nn
7.3.21.2 Data Description
EffectId:
Data Type: Unsigned 8 bit integer
Definition/Conversion: Appendix I MC-1 to MC-12 Effect ID Map.
7.3.21.3 MC-12 Response
The MC-12 will load the desired effect.
7.3.21.4 Data Validation
If a value is passed that exceeds the maximum value of that parameter the MC-12 will ignore the command
and transmit a NAK command with an error code DC_INVALID_DATA.
7.3.22 Set Record Input (MC-12, MC-1)
Sets the Record input.
This command has been maintained for backward compatibility with MC-1. In order to maintain backward
compatibility, the MC-12 Parameters have been mapped to the MC-1 parameters as described in each Data
Description. MC-12 users should be using the command described in 7.3.51 (MC12_Set_Record_Input).
7.3.22.1 Command Packet Description
