MV-5 Appendix A
A-3
*Depth measurement includes knobs, buttons, and terminal connections.
**For use with optional RF-1 Receiver.
Specifications are subject to change without notice.
Main Zone & Zone 2 Audio Performance
A/D conversion 24-bit, 96kHz, dual-bit ΔΣ
D/A conversion 24-bit, 44.1 to 192kHz, multi-bit ΔΣ
Input Sensitivity 200mV for Analog 1 to 6, and 200mV for 8-ch input
max input level: 2Vrms
Input Impedance 98.5kΩ for Analog 1 to 6, and 32kΩ for 8-ch input
Frequency Response 10Hz to 40kHz, +0, -2dB
THD + Noise <0.05%, 20Hz to 20kHz
Dynamic Range 100dB typical, 22 kHz bandwidth
Signal-to-Noise Ratio 100dB typical, 22kHz bandwidth
min 100dBA, 103dBA typical
Output Level 200mV typical, 6Vrms maximum
Output Impedance 570Ω
General
Power Requirements 90-250VAC, 50-60Hz, 50W (Universal line input)
IEC detachable power cords (supplied)
Power Consumption 3.76W at Power on, idle
47.2W at rated power output (HDMI in/out mode)
Dimensions • Height (with feet): 5.0 inches (127 mm)
• Height (without feet): 4.3 inches (109 mm)
• Width: 16.8 inches (426 mm)
• Depth*: 16.7 inches (423 mm)
Weight • Net Weight: 17.6 lb (8 kg)
• Gross Weight: 26.5 lb (12 kg)
Rack-Mounting Lexicon built rack mount kit not available.
Please seek alternative.
Operating
Environment
• Operating temperature: 0 to 45 C (32 to 113 F)
• Storage temperature: -20 to 60 C (-4 to 140 F)
• Relative humidity: 93% max without condensation
Remote Control Hand-held, back-lit, IR/RF** pre-programmed and learning
remote control (requires 4 AAA batteries – included)
