INDEX NO.

PART NO. DESCRIPTION

Q'TY

1 H03-ZVE21S90264-R-1 ASS'Y SMPS 90~264V UNIVERSIAL KWANG SUNG 1.0000

2 H03-ZUD0301ABBK-R-9 SPONGE-UL 30X30X12T BK 1.0000

3 H03-ZME21S07A00-R-1 CHASSIS FRONT MV-5 1.0000

4 H03-ZME21S08A00-R-2 COVER TOP MV-5 1.0000

5 H03-XDM202MD15G-R-3 DISPLAY VFD,M202MD15GK FUTABA 1.0000

6 H03-ZPE0604AA00-R-8 BUTTON FUNCTIONAL-LED RV-5 550-13634 28.0000

7 H03-ZME0615GAMW-R-5 VOLUMN KNOB AL RV-5 1.0000

8 H03-ZME0615GA00-R-4 VOLUMN KNOB D-SPRING RV-5 1.0000

9 H03-ZME21S01A00-R-6 AL PANEL FRONT MV-5 1.0000

10 H03-ZPE0602AA00-R-1 FILTER VFD RV-5 1.0000

11 H03-ZPE2101AA00-R-7 PANEL FRONT PLASTIC HIPS V2 SPRAY MV-5 SHIN BO 1.0000

12 H03-ZPE0603AA00-R-A BUTTON FUNCTIONAL RV-5 550-13633 2.0000

13 ZFNR19720SB-R-5 RUBBER FOOT 19.7X19.7X2T BK 4.0000

14 ZPC1103GAGY-R-A FOOT 50MM 15.8MM 4.0000

15 H03-ZME21S13A00-R-6 CHASSIS MAIN MV-5 1.0000

16 H03-ZME21S14A00-R-7 STANDOFF HEX M4X0.7 6X45.4H ,DONG SHIN 2.0000

17 H03-ZMD12S01C00-R-4 SHIELD DSP AVR745 1.0000

18 H03-SO3P5179GNN-R-9 JACK PHONE 3.5PI PJ0435179G 1.0000

19 H03-SOJB040131P-R-7 JACK RCA 4P,JB040131PG,DONGBO 2.0000

20 H03-SORA64105GN-R-3 JACK RCA 6P JB060132PG WWWRRR,GOLD COLOR 1.0000

21 H03-ZMD27S05A00-R-2 BKT IPOD 1.0000

22 H03-SORA40RSCGN-R-8 JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR 1.0000

23 H03-SORA1J440GE-R-9 JACK RCA 1P PPJ-440FEG PP ,GOLD COLOR 1.0000

24 H03-ZME21S12A00-R-5 STANDOFF HEX M4X0.7 6X74.6H,DONG SHIN 2.0000

25 H03-SORA40RSCGN-R-8 JACK RCA 4P JB040131QG WH BU RD GY,GOLD COLOR 1.0000

26 H03-SORA40RSAGN-R-4 JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR 1.0000

27 H03-SOYKC220873-R-0 YKC22-0873N JALCO 4.0000

28 H03-ZMD27S09A00-R-6 BKT XM DONGSHIN 1.0000

29 H03-SOJW2350SNN-R-7 JACK PHONE 3.6 EP-1401A 1P BK 1.0000

30 H03-SORA40021GN-R-7 JACK RCA+S-VIDEO 4P C80200212G DONGBO 1.0000

31 H03-SORA60031GN-R-4 JACK RCA+S-VIDEO 6P C80300312G,GOLD COLOR 1.0000

32 H03-SOR12BJ12GN-R-1 JACK RCA 12P BJ120154JG R4 BU4 G4,GOLD COLOR 1.0000

33 H03-SOYKF457009-R-2 JACK HDMI YKF45-7009 JALCO 3.0000

34 SOPA96063NN-R-0 JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1.0000

35 H03-ZME06S02A00-R-3 BKT GND SMALL,DONG BO 1.0000

36 H03-ZMC12S19A00-R-A BKT AC INLET 2.0000

37 H03-SOTU301ALY1-R-1 JACK AC INLET TU-301-AL-L-Y11E TECX-UNIONS 1.0000

38 H03-SWSDDJE1233-R-6 SDDJE12300 HOSODA 1.0000

39 H03-ZME21S02A00-R-7 PANEL REAR MV-5 1.0000

40 H03-SORA40RSAGN-R-4 JACK RCA 4P JB040131ZG GN BN PP TA ,GOLD COLOR 1.0000

41 H03-SWPVB25FHIN-R-A REB161 (9x7)PVB25FHINB1-2-24PCE NOBLE 1.0000

42 ZUC1201AABK-R-7 SPONGE 30X30X10T BK 1.0000

43 ZUE0601ABBK-R-5 SHIELD FORM GASKET 10X9X30(WxHxL)mm 9.0000

44 ZUE0601AABK-R-7 SHIELD FORM 3.0000

45 ZUE2101AABK-R SPONGE 10X30X3.0T 1.0000

L1 ZKE2195HA00-R-4 LABEL LICENSE MV-5 1.0000

L2 ZKE2130RV00-R-4 LABEL SERIAL MV-5 TF PRINT 1.0000

L3 ZKE0686AA00-R-A LABEL ORIGIN MADE IN P.R.C. 1.0000

L4 ZKC1281HA00-R-9 LABEL QC CHECK 2.0000

L5 ZKC1222HA00-R-2 LABEL RISK 1.0000

S1 ZSTWM3008BY SCREW ST W 3X8 25.0000

S2 ZSMWM3008BZ-R-7 SCREW M.S M3X8 W/H ZN PLATED 14.0000

S3 ZSTBM2508BW-R-1 SCREW 2.5X8 Zinc Plate WH 4.0000

S4 ZSTBM3010BB-R-5 SCREW ST BH 3X10 10.0000

S5 ZSMCM4008BY-R-1 SCREW BM 4X8 5.0000

S6 ZSMPM3006LB-R-A SCREW.M.S.M3X6 P/HD BLACK 3.0000

S7 ZSTGM3010BB-R-3 SCREW ST BH 3X10 GROUND 36.0000

S8 ZSTWM4008BB-R SCREW ST WPH 4X8 8.0000

SP H03-ZMB01S02200-R-6 SPRING PLATE GND C5212 0.2T 1.0000

2.0000

W1 ZWM623108SZ-R-2 WASHER SPRING 3 2.0000

END

MV-5 EXPLODED VIEW PART LIST
