Lexicon MV-5 Protocol Manual

Lexicon RV-5/MV-5 Serial Communications Protocol
4 Command Data
PC -> AVR, Data length: 4 byte
Information Field (HEX )
Selected
Input
COMMAND
1st 2nd 3rd 4th
Standby Power On 82 0B 9A 65
Standby Power Off 82 0B 9B 64
Main MUTE (toggle) 82 0B 15 EA
Main HD select 82 0B 20 DF
Main DVD select 82 0B 21 DE
Main Game select 82 0B 34 CB
Main SAT select 82 0B 24 DB
Main CABLE select 82 0B 23 DC
Main DVR select 82 0B 25 DA
Main CD select 82 0B 26 D9
Main Dock select 82 0B 38 C7
Main PC select 82 0B 39 C6
Main Tuner select 82 0B 2A D5
Main Aux1 select 82 0B 2B D4
Main Aux2 select 82 0B 32 CD
Main Volume + (cw) 82 0B 17 E8
Main Volume - (ccw) 82 0B 16 E9
√
Mode < 82 0B 1B E4
√
Mode > 82 0B 1A E5
√
Video Status (toggle) 82 0B 5C A3
√
Audio status (toggle) 82 0B 1C E3
MENU select 82 0B 09 F6
(Menu) UP 82 0B 01 FE
(Menu) DOWN 82 0B 1D E2
(Menu) LEFT 82 0B 0A F5
(Menu) RIGHT 82 0B 08 F7
