Clearing jams guide
Page 4 of 10
3 Pull the fuser pressure release levers to release tension on the media.
4 Grasp each side of the jammed media. Pull it to the rear of the printer and then out.
Note: Gently pull the media out so you do not tear it.
5 Close the rear door.
Fuser pressure release lever
Fuser
pressure
release
lever
