Lexmark C748e User Manual

Emitted
Substance
Product Measurement
(Color)
Maximum according
to Guideline (Color)
Ozone (mg/h)
<0.06
3
Styrene (mg/h)
0.9
1.8
Benzene (mg/h)
<0.03
<0.05
Dust (mg/h)
<0.7
4.0
TVOC (mg/h)
8.0
18
*Note: The print test is performed using genuine Lexmark supplies. Emissions
may vary if using non-Lexmark supplies.
Product Restricted Materials
The reduction of materials harmful to persons or the environment is a
significant part of Lexmark's commitment to continuously improving the
environmental design of all our products and services. Lexmark has
developed a multi-layered due diligence process to ensure that all
materials going into Lexmark products are safe and compliant with
global regulations regarding hazardous substances.
This product is compliant with the requirements of the European Union's
Directive 2002/95/EC on the Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment (RoHS).
This product is compliant with the requirements of the European Union’s
Registration, Evaluation, Authorization and Restriction of Chemicals
(REACH) regulation.
This product and its packaging are labeled as required by China’s
“Management Methods for Controlling Pollution by Electronic Information
Products.”
The product does not contain:
Cadmium
Hexavalent chromium
Polybrominated biphenyls
Polybrominated diphenyl ethers
Mercury
Asbestos
Short chain chlorinated paraffins
Polychlorinated phenols
Polychlorinated terphenyls
Ozone depleting chemicals (Chlorofluorocarbons (CFCs), halons,
HCFCs, HBFCs, 1,1,1-trichlorethane, carbon tetrachloride, methyl
bromide)
Halogenated flame retardants in cover sets
This product contains the following in limited quantities as allowed
by regulations:
Lead (use is limited to small amounts for specific applications)
Battery Usage
The battery contained within this product does not contain cadmium,
mercury, or lead.
Battery Type: Lithium Manganese Dioxide coin cell
Weight: ~ 0.23 g
Customer removable: No
Recyclable Design
Mechanical plastic parts over 100g consist of one or more easily
separable materials.
Use of non-separable connections between different materials, such as
gluing or welding, has been avoided.
Product Description:
Measurements provided are for a non-packaged
product.
Weight 22.90 kg | 50.49 lbs (without cartridge)
Width 435 mm | 17.13 in
Depth 400 mm | 15.75 in
Height 455 mm | 17.91 in
Due to printer weight this printer requires at least two
people to lift it safely. For additional information consult the
setup guide.
Operational Data
Speed (Letter – ppm) Up to: 35 Speed (A4 - ppm) Up to: 33
Power
Printing Simplex
533 W
Ready
48 W
Sleep
7.3 W
Hibernate
0.55 W
Off
0 W
Typical Electricity Consumption Test
(TEC)
3.687 kwh/week
Typical Electricity Consumption Test
Eco-Mode (TEC)
2.491 kwh/week
Acoustic
Noise
Printing Simplex (mono / color)
54 dBA / 55 dBA
Printing Quiet Mode (mono / color)
47 dBA / 48 dBA
Idle
32 dBA
*Note: These measurements are subject to change
Chemical Emissions
Printer emissions testing is performed in accordance with the “Test
method for the determination of emissions from hardcopy devices with
respect to awarding the environmental label for office devices with
printing function according to RAL-UZ 122”, BAM April 2006.
Emitted
Substance
Product Measurement
(Monochrome)
Maximum according
to Guideline (Mono)
Ozone (mg/h)
<0.06
1.5
Styrene (mg/h)
0.14
1.0
Benzene (mg/h)
<0.03
<0.05
Dust (mg/h)
<0.7
4.0
TVOC (mg/h)
0.80
10

Lexmark C748e Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, draft quality, A4/US Letter)	33 ppm
Print speed (black, normal quality, A4/US Letter)	- ppm
Wi-Fi	No
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Recommended duty cycle	10000 pages per month
Number of print cartridges	-
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS, XHTML
Maximum internal memory	1536 MB
Sound power level (standby)	32 dB
Sound pressure level (printing)	55 dB
Sound pressure level (quiet mode)	48 dB
Display	LCD
Certification	CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, FCC Class B, UL 60950-1, EN/IEC 60320-1, CE Class B, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class B, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class B, CCC Class B, CISPIR 22 Class B, MIC Mark, EK Mark
Product color	Grey, White
Total input capacity	650 sheets
Total output capacity	300 sheets
Maximum input capacity	4300 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-422)
Other operating systems supported	IBM AS/400, IBM iSeries, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64
Power consumption (printing)	- W
Package weight	30100 g
Networking features	Gigabit Ethernet
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	435 x 400 x 455 mm
