417
4-3. Do-it-yourself maintenance
4
Maintenance and care
Fuse Ampere Circuit
9
DOME
10
Foot lights, Vanity lights, Gauges and
meters, Steering spot light, Steering
switch illumination, Rear personal
lights, Automatic transmission selec-
tor lever spot light, Front personal
lights
10
CDS
10
NOIS FILTER
11
ABS MAIN2
10
ECB system
12
ABS MOTOR
30
ABS
13
ABS MAIN1
10
Capacitor
14
E/G-B
60
FR CTRL BATT, ECTS and ALT-S
15
ABS1
50
VSC system, ABS MAIN1, ABS
MAIN2 and ABS MTR
16
RH J/B-B
30
AM2, DOOR FR, and DOOR RR
17
VGRS
40
VGRS
18
MAIN
30
H-LP R LWR and H-LP L LWR
19
STARTER
30
Starting system
20
LH J/B-B
30
FL DOOR, RL DOOR and RND
NO.3
21
P/ I- B
60
Multi-port fuel injection system/
sequential multiport fuel injection
system
22
EPS
80
EPS
23
ALT
150
RH J/B-AM, LH J/B-AM, E/G-AM,
RR JB, HEATER, DEFOG, FAN1,
FAN2, ABS2, ABS MOTOR,
ABS MAIN1, and ABS MAIN2
