Lexus 2007 GS430 - Page 492

418
4-3. Do-it-yourself maintenance
Fuse Ampere Circuit
24
RR J/B
80
STOP LP R, STOP LP L, RR-B,
RR TAIL, RR FOG, RR-IG1, PSB,
and RR S/SHADE
25
GLW PLG1
50
Glow plug heater
26
RH J/B-AM
80
AM1, OBD, STOP SW, TI&TE,
PWR OUTLET, FR P/SEAT RH,
STR LOCK, ECU-IG RH, RH-IG,
ACC, CIG, SECURITY,
FR S/HER RH and AIR SUS
27
ABS2
30
VSC, ABS
28
DEFOG
50
Rear window defogger, Noise filter
29
CDS
40
F: CDS
30
FAN 1
40
Electric cooling fans
31
HEATER
50
Air conditioning system
32
GLW PLG2
50
Glow plug heater
33
E/G-AM
60
H-LMP CLN, FR CTRL-AM and
A/C COMP
34
LH J/B-AM
80
S/ROOF, FR P/SEAT LH, TV,
FR S/HTR LH, FR WIP, H-LP LVL,
LH-IG, FUEL OPEN, A/C, PANEL
and LH-B
35
FAN 2
60
