816
4-3. Do-it-yourself maintenance
35
ECU-IG1 NO. 4 10 A
Air conditioning system, rear window
defogger, electronically controlled
brake system, electric cooling fans
36
BK/UP LP 7.5 A Back-up lights
37
ECU-IG1 NO. 5 15 A Air conditioning system
38
ECU-IG1 NO. 6 10 A
Head light cleaner, cruise control, air
conditioning system, Blind Spot Moni-
tor
39
EFI NO. 2 10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
40
F/P MP 15 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
41
DEICER 25 A Windshield wipers and washer
42
STOP 7.5 A
Vehicle Proximity Notification System,
vehicle dynamics integrated manage-
ment, stop lights, multiport fuel injec-
tion system/sequential multiport fuel
injection system, shift lock control sys-
tem, starter system, cruise control
43
TOWING BATT 20 A
44
TOWING 30 A Trailer lights
45
FILTER 10 A
46
IG1 MAIN 30 A
ECU-IG1 NO. 6, BK/UP LP, ECU-
IG1 NO. 5, ECU-IG1 NO. 4
47
H-LP RH HI 15 A Right-hand headlight (high beam)
48
H-LP LH HI 15 A Left-hand headlight (high beam)
Fuse Ampere Circuit
To Next Page
