ELECTRICAL COMPONENTS
578
No. FUSE AMPERE CIRCUIT
28 ECU−IG LH 10
Vehicle stability control system,
Electronic control brake system,
Yaw rate and G sensor,
Steering sensor, Cruise control
system, Dynamic radar cruise
control system, Electronic
power steering system, Variable
gear ratio steering system,
Rear view monitor system,
Four−wheel drive system, Front
controller, Moon roof, Rain
sensor
29
FR S/HTR
LH
15
Seat heater, Heated and
ventilated seats
30
FR P/SEAT
LH
30
Power seat system
31 A/C 7.5 Air conditioning system
32 TV 7.5
Audio system, Air conditioning
system, Rear view monitor
system
33 TRK OPN 10 Trunk lid opener
34 LH−B 10 Theft deterrent system
35 S/ROOF 25 Moon roof
36 ECU−B 10
Variable gear ratio steering
system, Electronic power
steering system, Driver’s seat
switch module
37
ABS
MAIN3
10
Electronic control brake system
No. FUSE AMPERE CIRCUIT
38 TURN−HAZ 15
Turn signal lights, Emergency
flashers
39 IG2 MAIN 20 “IG2”, “GAUGE” and “IGN”
40 RAD NO.2 30 Audio system
41 D/C CUT 20 “DOME “ and “MPX−B”
42 RAD NO.1 30 Audio system
43 MPX−B 10
Multiplex communication
system, Front controller, Door
control system (Power door
lock system, Door courtesy
lights, Power windows, Power
rear view mirror control system,
Outside rear view mirror
heaters), Power seat system,
Steering sensors, Electronic
control brake system, Power tilt
and telescopic steering system,
Gauges and meters,
Combination switch
44 DOME 10
Foot lights, Vanity lights,
Gauges and meters, Steering
spot light, Steering switch
illumination, Rear personal
lights, Automatic transmission
selector lever spot light, Front
personal lights
45
ABS
MAIN2
10
Electronic control brake system
46
ABS
MOTOR
30
Anti−lock brake system
