ELECTRICAL COMPONENTS
579
No. FUSE AMPERE CIRCUIT
47
ABS
MAIN1
10
Capacitor
48 E/G−B 60
“FR CTRL BATT”, “ETCS” and
“ALT−S”
49 ABS1 50
Vehicle stability control system,
“ABS MAIN1”, “ABS MAIN2”
and “ABS MTR”
50 RH J/B−B 30
“AM2”, “DOOR FR” and “DOOR
RR”
51 VGRS 40
Variable gear ratio steering
system
52 MAIN 30
“H−LP R LWR” and “H−LP L
LWR”
53 STARTER 30 Starting system
54 LH J/B−B 30
“FL DOOR”, “RL DOOR” and
“RAD No.3”
55 P/I−B 60
Multi−port fuel injection
system/sequential multiport fuel
injection system
56 EPS 80
Electronic power steering
system
57 ALT 150
“RH J/B−AM”, “LH J/B−AM”,
“E/G−AM”, “RR JB”, “HEATER”,
“DEFOG”, “FAN1”, “FAN2”,
“ABS2”, “ABS MOTOR”, “ABS
MAIN1”, and “ABS MAIN2”
No. FUSE AMPERE CIRCUIT
58 RR J/B 80
“STOP LP R”, “STOP LP L”,
“RR−B”, “RR TAIL”, “RR FOG”,
“RR−IG1”, “PSB”, and “RR
S/SHADE”
59 GLW PLG1 50 Glow plug heater
60 RH J/B−AM 80
“AM1”, “OBD”, “STOP SW”, “TI
&TE”, “PWR OUTLET”, “FR
P/SEAT RH”, “STR LOCK”,
“ECU−IG RH”, “RH−IG”, “ACC”,
“CIG”, “SECURITY”, “FR
S/HTR RH”, and “AIR SUS”
61 ABS2 30
Vehicle stability control system,
Anti−lock brake system
62 DEFOG 50
Rear window defogger, Noise
filter
63 FAN1 40 Electric cooling fans
64 HEATER 50 Air conditioning system
65 GLW PLG2 50 Glow plug heater
66 E/G−AM 60
“H−LMP CLN”, “FR CTRL−AM”
and “A/C COMP”
67
LH J/
B−AM
80
“S/ROOF”, “FR P/SEAT LH”,
“TV”, “FR S/HTR LH”, “ECU−IG
LH”, “FR WIP”, “H−LP LVL”,
“LH−IG”, “FUEL OPEN”, “A/C”,
“PANEL”, and “LH−B”
68 FAN2 60 No circuit
69
FR
CTRL−B
25
“H−LP UPR” and “HORN”
