ELECTRICAL COMPONENTS
580
No. FUSE AMPERE CIRCUIT
70 A/F 15
Multi−port fuel injection
system/sequential multiport fuel
injection system
71 ETCS 10
Multi−port fuel injection
system/sequential multiport fuel
injection system
72 ALT−S 7.5 Charging system
73 EM VLV 10 No circuit
74 H−LP CLN 30 Headlight cleaner system
75 A/C COMP 7.5 Air conditioning system
76 DEICER 25 No circuit
77
FR
CTRL−AM
30
“FR TAIL”, “FR FOG” and
“WASHER”
78 IG2 10 Starting system
79 EFI NO.2 10
Multi−port fuel injection
system/sequential multiport fuel
injection system, Evaporative
system
80
H−LP R
LWR
15
Right−hand headlight (low
beam)
81
H−LP L
LWR
15
Left−hand headlight (low beam)
82 F/PMP 25 Fuel pump
No. FUSE AMPERE CIRCUIT
83 EFI
GS430:
20
GS300:
25
Multi−port fuel injection
system/sequential multiport fuel
injection system
84 INJ 20
Multi−port fuel injection
system/sequential multiport fuel
injection system
85 H−LP UPR 15 Headlights (high beam)
86 HORN 10 Horn
87 WASHER 20 Windshield wipers and washer
88 FR TAIL 10
Parking lights, Side marker
lights
89 FR FOG 15 Front fog lights
90
RR
S/SHADE
7.5
Rear electric sunshade
91 PSB 30 Pre−collision system
92 RR−IG2 10 No circuit
93 RR−IG1 10
Pre−collision system, Rear
electric sunshade, Seat belt
pretensioners
94 RR−B 10
Luggage compartment light,
Noise filter
95 RR FOG 7.5 Rear fog lights
96 STOP LP L 10 Stoplights, Back up lights
