451
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EE
9
ACC 7.5 A
Clock, audio, navigation system,
outside rear view mirrors, smart
entry & start system, Lexus park-
ing assist monitor, glove box light,
console box light, multiplex com-
munication system, display
10
CIG 15 A Cigarette lighter
11
PWR OUTLET 15 A Power outlet
12
RR DOOR RH 20 A Power windows
13
FR DOOR RH 20 A
Power windows, outside rear view
mirrors, multiplex communication
system
14
AM2 7.5 A Smart entry & start system
15
RH-IG 7.5 A
Seat belts, automatic transmis-
sion, seat heaters and ventilators,
windshield wiper de-icer, power
heater
16
FR S/HTR RH 15 A Seat heaters and ventilators
17
ECU-IG RH 10 A
Power seat, headlights, front fog
lights, front position lights, license
plate lights, windshield washer,
outside rear view mirror, VDIM,
air conditioning system, pre-crash
seat belt, electric tilt and telescopic
steering column, power windows,
navigation system, vehicle stabil-
ity control, multiplex communica-
tion system, smart entry & start
system
Fuse Ampere Circuit
