Hybrid Vehicle (HV) Battery Pack and Auxiliary Battery (Continued)
HV Battery Pack Recycling
• The HV battery pack is recyclable. Contact either your Lexus Distributor as mentioned on HV
battery Caution Label (see page 36) or the nearest Lexus dealer.
Auxiliary Battery
• The IS300h contains a sealed lead-acid 12 Volt battery. This 12 Volt auxiliary battery powers the
vehicle electrical system similar to a conventional vehicle. As with other conventional vehicles,
the negative terminal of the auxiliary battery is grounded to the metal chassis of the vehicle.
• The auxiliary battery is located in the trunk area. It is concealed by a fabric cover on the left side
in the rear quarter panel well.
230.4 Volt HV Battery Pack
12 Volt Auxiliary Battery Mounted in the Trunk
Area
HV Battery Pack (Viewed from the Trunk Area)
11
