25. REMOVE LUGGAGE COMPARTMENT
TRIM COVER LH
(1) Disengage the 4 claws and open the 2
covers.
(2) Remove the 2 bolts and 2 rope hook
assembly.
(3) Remove the 6 clips.
29
