30
34. Moving the HV battery.
Caution:
Wear insulated gloves.
(1) Remove the 2 nuts, clamp and wire
harness protector.
(2) Release the claw and remove the 2
nuts and separate the frame wire
from the luggage room junction
block.
(3) Disconnect the connector,
disengage the 4 clamps and move
the frame wire.
To Next Page
