32
(10) Disconnect the battery pack wire
connector.
(11) Remove the 2 clips, 4 nuts, 2 bolts
and 2 HV battery brackets.
(12) Remove the 3 bolts for the front
part of the HV battery from the
cabin side.
(13) Install the luggage compartment floor mat upside down.
To Next Page
