a. Slide the clip and disconnect the suction hose from the vane pump.
10. DISCONNECT POWER STEERING OIL PRESSURE SENSOR CONNECTOR
a. Detach the wire harness clamp and disconnect the connector.
11. DISCONNECT PRESSURE FEED TUBE
a. Remove the bolt and disconnect the pressure feed tube.
b. Remove the gasket.
12. REMOVE VANE PUMP ASSEMBLY
a. Remove the 2 bolts and vane pump.
