8. REMOVE VANE PUMP FRONT SIDE PLATE
a. Remove the front side plate from the front housing.
b. Using a screwdriver, remove the O-ring from the front side plate.
HINT:
Tape the screwdriver tip before use.
c. Remove the O-ring from the front housing.
9. REMOVE VANE PUMP HOUSING OIL SEAL
a. Using a screwdriver and piece of cloth, pry out the oil seal.
NOTICE:
Be careful not to damage the front housing.
