b. Detach the clip and remove the cover.
13. REMOVE INSTRUMENT SIDE PANEL LH
a. Place protective tape as shown in the illustration.
b. Using a moulding remover, detach the 6 claws and remove the side panel.
14. REMOVE NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY
a. Detach the 4 claws and remove the register.
15. REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY
a. Detach the 5 claws and remove the register.
16. REMOVE NO. 1 SWITCH HOLE BASE
