19. REMOVE NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY
a. Remove the 2 screws.
b. Detach the 3 claws.
c. Remove the under cover and disconnect the connectors.
20. REMOVE COWL SIDE TRIM BOARD LH
a. Remove the cap nut.
b. Detach the 2 clips and remove the trim board.
21. REMOVE LOWER NO. 1 INSTRUMENT PANEL FINISH PANEL
a. Using a screwdriver, detach the 2 claws and open the hole cover.
HINT:
Tape the screwdriver tip before use.
